NXP Semiconductors/Freescale Semiconductor, Inc. S9S12G128F0VLF
- Mfg. Part Number
- S9S12G128F0VLF
- Manufacturer
- NXP Semiconductors/Freescale Semiconductor, Inc.
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 16BIT 128KB FLASH 48LQFP
- Datasheet Download
- S9S12G128F0VLF.pdf
Availability of S9S12G128F0VLF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.95201
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of S9S12G128F0VLF, we specialize in NXP Semiconductors/Freescale Semiconductor, Inc. all series electronic components. S9S12G128F0VLF can be shipped within 24 hours after order. If you have any demands for S9S12G128F0VLF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- S9S12G128F0VLF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
S9S12G128F0VLF
| Internal Part Number | EIS-S9S12G128F0VLF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| PCN Design/Specification | S12G64,128,240 and GA240 Cu Wire 03/Oct/2013 Reference Manual Update 06/Aug/2014 | |
| Standard Package | 1,250 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | HCS12 | |
| Packaging | Tray | |
| Core Processor | 12V1 | |
| Core Size | 16-Bit | |
| Speed | 25MHz | |
| Connectivity | CAN, IrDA, LIN, SCI, SPI | |
| Peripherals | LVD, POR, PWM, WDT | |
| Number of I/O | 40 | |
| Program Memory Size | 128KB (128K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | 4K x 8 | |
| RAM Size | 8K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 3.13 V ~ 5.5 V | |
| Data Converters | A/D 12x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 105°C | |
| Package / Case | 48-LQFP | |
| Supplier Device Package | 48-LQFP (7x7) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | S9S12G128F0VLF | |
| Related Links | S9S12G1, S9S12G128F0VLF Datasheet, NXP Semiconductors/Freescale Semiconductor, Inc. Distributor | |
S9S12G128F0VLF Details Description
