Infineon Technologies SAK-XC2336B-40F80L AA
- Mfg. Part Number
- SAK-XC2336B-40F80L AA
- Manufacturer
- Infineon Technologies
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 16BIT 320KB FLASH 64LQFP
- Datasheet Download
- SAK-XC2336B-40F80L AA.pdf
Availability of SAK-XC2336B-40F80L AA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.75114
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SAK-XC2336B-40F80L AA, we specialize in Infineon Technologies all series electronic components. SAK-XC2336B-40F80L AA can be shipped within 24 hours after order. If you have any demands for SAK-XC2336B-40F80L AA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SAK-XC2336B-40F80L AA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SAK-XC2336B-40F80L AA
| Internal Part Number | EIS-SAK-XC2336B-40F80L AA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| PCN Design/Specification | Copper Bond Wire 26/Feb/2014 | |
| Standard Package | 1,900 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | XC23xxB | |
| Packaging | Tape & Reel (TR) | |
| Core Processor | C166SV2 | |
| Core Size | 16/32-Bit | |
| Speed | 80MHz | |
| Connectivity | CAN, EBI/EMI, I²C, LIN, SPI, SSC, UART/USART, USI | |
| Peripherals | I²S, POR, PWM, WDT | |
| Number of I/O | 38 | |
| Program Memory Size | 320KB (320K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 34K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 3 V ~ 5.5 V | |
| Data Converters | A/D 9x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 64-LQFP Exposed Pad | |
| Supplier Device Package | PG-LQFP-64-6 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SAK-XC2336B-40F80L AA | |
| Related Links | SAK-XC2336, SAK-XC2336B-40F80L AA Datasheet, Infineon Technologies Distributor | |
SAK-XC2336B-40F80L AA Details Description
