Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
Internal Part Number | EIS-SBL1030CT-E3/45 | |
Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
Production Status (Lifecycle) | In Production | |
Condition | New & Unused, Original Sealed | |
Video File | Functions & Parameters of the “Simplest” Semiconductor | |
Standard Package | 50 | |
Category | Discrete Semiconductor Products | |
Family | Diodes, Rectifiers - Arrays | |
Series | - | |
Packaging | Tube | |
Diode Configuration | 1 Pair Common Cathode | |
Diode Type | Schottky | |
Voltage - DC Reverse (Vr) (Max) | 30V | |
Current - Average Rectified (Io) (per Diode) | 5A | |
Voltage - Forward (Vf) (Max) @ If | 550mV @ 5A | |
Speed | Fast Recovery =< 500ns, > 200mA (Io) | |
Reverse Recovery Time (trr) | - | |
Current - Reverse Leakage @ Vr | 500µA @ 30V | |
Mounting Type | Through Hole | |
Package / Case | TO-220-3 | |
Supplier Device Package | TO-220AB | |
Weight | 0.001 KG | |
Application | Email for details | |
Alternative Part (Replacement) | SBL1030CT-E3/45 | |
Related Links | SBL1030, SBL1030CT-E3/45 Datasheet, Vishay Semiconductor/Diodes Division Distributor |
