Diodes Incorporated SBRT10U50SP5-13
- Mfg. Part Number
- SBRT10U50SP5-13
- Manufacturer
- Diodes Incorporated
- Product Category
- Diodes, Rectifiers - Single
- Brief Description
- DIODE SBR 50V 10A POWERDI5
- Datasheet Download
- SBRT10U50SP5-13.pdf
Availability of SBRT10U50SP5-13
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SBRT10U50SP5-13, we specialize in Diodes Incorporated all series electronic components. SBRT10U50SP5-13 can be shipped within 24 hours after order. If you have any demands for SBRT10U50SP5-13, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SBRT10U50SP5-13 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SBRT10U50SP5-13
| Internal Part Number | EIS-SBRT10U50SP5-13 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Mold Compound/Solder Update 09/Jan/2015 | |
| Standard Package | 1 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes, Rectifiers - Single | |
| Series | SBR® | |
| Packaging | Cut Tape (CT) | |
| Diode Type | Super Barrier | |
| Voltage - DC Reverse (Vr) (Max) | 50V | |
| Current - Average Rectified (Io) | 10A | |
| Voltage - Forward (Vf) (Max) @ If | 450mV @ 10A | |
| Speed | Standard Recovery >500ns, > 200mA (Io) | |
| Reverse Recovery Time (trr) | - | |
| Current - Reverse Leakage @ Vr | 75mA @ 50V | |
| Capacitance @ Vr, F | - | |
| Mounting Type | Surface Mount | |
| Package / Case | PowerDI™ 5 | |
| Supplier Device Package | PowerDI™ 5 | |
| Operating Temperature - Junction | -55°C ~ 150°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SBRT10U50SP5-13 | |
| Related Links | SBRT10U, SBRT10U50SP5-13 Datasheet, Diodes Incorporated Distributor | |
SBRT10U50SP5-13 Details Description
