Kingbright SC04-11SRWA
- Mfg. Part Number
- SC04-11SRWA
- Manufacturer
- Kingbright
- Product Category
- Display Modules - LED Character and Numeric
- Brief Description
- DISPLAY 0.4" SGL 640NM RED
- Datasheet Download
- SC04-11SRWA.pdf
Availability of SC04-11SRWA
Available Quantity
5644 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.58800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SC04-11SRWA, we specialize in Kingbright all series electronic components. SC04-11SRWA can be shipped within 24 hours after order. If you have any demands for SC04-11SRWA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SC04-11SRWA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SC04-11SRWA
| Internal Part Number | EIS-SC04-11SRWA | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | Sx04-11x.sldprtSx04-11x.proSx04-11x.igsSx04-11x.stp | |
| Standard Package | 27 | |
| Category | Optoelectronics | |
| Family | Display Modules - LED Character and Numeric | |
| Series | - | |
| Number of Characters | 1 | |
| Size / Dimension | 0.738" H x 0.386" W x 0.200" D (18.75mm x 9.80mm x 5.08mm) | |
| Digit/Alpha Size | 0.40" (10.16mm) | |
| Display Type | 7-Segment | |
| Common Pin | Common Cathode | |
| Color | Red | |
| Voltage - Forward (Vf) (Typ) | 1.85V | |
| Current - Test | 20mA | |
| Millicandela Rating | 30mcd | |
| Wavelength - Peak | 660nm | |
| Power Dissipation (Max) | 75mW | |
| Package / Case | 14-DIP (0.295", 7.50mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SC04-11SRWA | |
| Related Links | SC04-, SC04-11SRWA Datasheet, Kingbright Distributor | |
SC04-11SRWA Details Description
