Semtech SC196AMLTRT
- Mfg. Part Number
- SC196AMLTRT
- Manufacturer
- Semtech
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG BUCK PROG 1.5A SYNC 10MLP
- Datasheet Download
- SC196AMLTRT.pdf
Availability of SC196AMLTRT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.38373
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SC196AMLTRT, we specialize in Semtech all series electronic components. SC196AMLTRT can be shipped within 24 hours after order. If you have any demands for SC196AMLTRT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SC196AMLTRT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SC196AMLTRT
| Internal Part Number | EIS-SC196AMLTRT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Function | Step-Down | |
| Output Configuration | Positive | |
| Topology | Buck | |
| Output Type | Programmable | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 2.7V | |
| Voltage - Input (Max) | 5.5V | |
| Voltage - Output (Min/Fixed) | 1V, 1.05V, 1.2V, 1.8V | |
| Voltage - Output (Max) | - | |
| Current - Output | 1.5A | |
| Frequency - Switching | 1MHz | |
| Synchronous Rectifier | Yes | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 10-VFDFN Exposed Pad | |
| Supplier Device Package | 10-MLP (3x3) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SC196AMLTRT | |
| Related Links | SC196, SC196AMLTRT Datasheet, Semtech Distributor | |
SC196AMLTRT Details Description
