Semtech SC2442HITSTRT
- Mfg. Part Number
- SC2442HITSTRT
- Manufacturer
- Semtech
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Controllers
- Brief Description
- IC CTRLR BUCK PWM 24TSSOP
- Datasheet Download
- SC2442HITSTRT.pdf
Availability of SC2442HITSTRT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.87211
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SC2442HITSTRT, we specialize in Semtech all series electronic components. SC2442HITSTRT can be shipped within 24 hours after order. If you have any demands for SC2442HITSTRT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SC2442HITSTRT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SC2442HITSTRT
| Internal Part Number | EIS-SC2442HITSTRT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Controllers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Number of Outputs | 2 | |
| Frequency - Max | 1.1MHz | |
| Duty Cycle | 94% | |
| Voltage - Supply | 4.75 V ~ 36 V | |
| Buck | Yes | |
| Boost | No | |
| Flyback | No | |
| Inverting | No | |
| Doubler | No | |
| Divider | No | |
| Cuk | No | |
| Isolated | No | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 24-TSSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 24-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SC2442HITSTRT | |
| Related Links | SC2442, SC2442HITSTRT Datasheet, Semtech Distributor | |
SC2442HITSTRT Details Description
