Bel Fuse Inc. SC312MF-2R2
- Mfg. Part Number
- SC312MF-2R2
- Manufacturer
- Bel Fuse Inc.
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 2.2UH 1.2A 157 MOHM
- Datasheet Download
- SC312MF-2R2.pdf
Availability of SC312MF-2R2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.49332
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SC312MF-2R2, we specialize in Bel Fuse Inc. all series electronic components. SC312MF-2R2 can be shipped within 24 hours after order. If you have any demands for SC312MF-2R2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SC312MF-2R2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SC312MF-2R2
| Internal Part Number | EIS-SC312MF-2R2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | RoHS Compliance | |
| Featured Product | SC Series SMD Power Inductors | |
| Standard Package | 3,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | SC312MF | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | - | |
| Inductance | 2.2µH | |
| Tolerance | ±20% | |
| Current Rating | 1.2A | |
| Current - Saturation | 2A | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 157 mOhm Max | |
| Q @ Freq | - | |
| Frequency - Self Resonant | - | |
| Operating Temperature | - | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.150" L x 0.150" W (3.80mm x 3.80mm) | |
| Height - Seated (Max) | 0.053" (1.35mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SC312MF-2R2 | |
| Related Links | SC312, SC312MF-2R2 Datasheet, Bel Fuse Inc. Distributor | |
SC312MF-2R2 Details Description
