Mallory Sonalert Products SC616NPUR
- Mfg. Part Number
- SC616NPUR
- Manufacturer
- Mallory Sonalert Products
- Product Category
- Buzzers
- Brief Description
- BUZZER PIEZO 42.9MM PANEL MOUNT
- Datasheet Download
- SC616NPUR.pdf
Availability of SC616NPUR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 61.94000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SC616NPUR, we specialize in Mallory Sonalert Products all series electronic components. SC616NPUR can be shipped within 24 hours after order. If you have any demands for SC616NPUR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SC616NPUR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SC616NPUR
| Internal Part Number | EIS-SC616NPUR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Sound File | 3000 Hz Dual Mode C/FP | |
| 3D Model | SC1.igsSC1.satSC1.stp | |
| Standard Package | 1 | |
| Category | Audio Products | |
| Family | Buzzers | |
| Series | SC | |
| Packaging | Bulk | |
| Driver Circuitry | Indicator, Internally Driven | |
| Technology | Piezo | |
| Input Type | DC | |
| Voltage - Rated | - | |
| Voltage Range | 6 ~ 16V | |
| Frequency | 2.9kHz | |
| Operating Mode | Continuous, Fast Pulse | |
| Sound Pressure Level | 80dB @ 6V, 61cm | |
| Current - Supply | 30mA | |
| Operating Temperature | -30°C ~ 65°C | |
| Washable | No | |
| Port Location | Top | |
| Mounting Type | Panel Mount | |
| Termination | Quick Connect Tab - 0.250" (6.35mm) | |
| Size / Dimension | 42.9mm Dia x 32.9mm H | |
| Capacitance @ Frequency | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SC616NPUR | |
| Related Links | SC61, SC616NPUR Datasheet, Mallory Sonalert Products Distributor | |
SC616NPUR Details Description
