Mallory Sonalert Products SC628H-BTR
- Mfg. Part Number
- SC628H-BTR
- Manufacturer
- Mallory Sonalert Products
- Product Category
- Buzzers
- Brief Description
- BUZZER PIEZO 42.9MM PANEL MOUNT
- Datasheet Download
- SC628H-BTR.pdf
Availability of SC628H-BTR
Available Quantity
5025 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 16.66128
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SC628H-BTR, we specialize in Mallory Sonalert Products all series electronic components. SC628H-BTR can be shipped within 24 hours after order. If you have any demands for SC628H-BTR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SC628H-BTR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SC628H-BTR
| Internal Part Number | EIS-SC628H-BTR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Sound File | 4500 Hz Continuous | |
| Featured Product | 30 mm Panel Mounts Quick-Connect Termination | |
| 3D Model | SCF.igsSCF.satSCF.stp | |
| Standard Package | 1 | |
| Category | Audio Products | |
| Family | Buzzers | |
| Series | SC | |
| Packaging | Bulk | |
| Driver Circuitry | Indicator, Internally Driven | |
| Technology | Piezo | |
| Input Type | DC | |
| Voltage - Rated | - | |
| Voltage Range | 6 ~ 28V | |
| Frequency | 4.5kHz | |
| Operating Mode | Continuous | |
| Sound Pressure Level | 68dB @ 6V, 61cm | |
| Current - Supply | 6 ~ 23mA | |
| Operating Temperature | -30°C ~ 65°C | |
| Washable | No | |
| Port Location | Top | |
| Mounting Type | Panel Mount | |
| Termination | Quick Connect Tab - 0.250" (6.35mm) | |
| Size / Dimension | 42.9mm Dia | |
| Capacitance @ Frequency | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SC628H-BTR | |
| Related Links | SC628, SC628H-BTR Datasheet, Mallory Sonalert Products Distributor | |
SC628H-BTR Details Description
