Bourns Inc. SDR2207-181KL
- Mfg. Part Number
- SDR2207-181KL
- Manufacturer
- Bourns Inc.
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 180UH 1.3A 300 MOHM
- Datasheet Download
- SDR2207-181KL.pdf
Availability of SDR2207-181KL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.70560
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SDR2207-181KL, we specialize in Bourns Inc. all series electronic components. SDR2207-181KL can be shipped within 24 hours after order. If you have any demands for SDR2207-181KL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SDR2207-181KL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SDR2207-181KL
| Internal Part Number | EIS-SDR2207-181KL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Magnetic Product Overview | |
| RoHS Information | SDR2207 Series Material Declaration | |
| PCN Assembly/Origin | Magnetic products Oct/2013 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 250 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | SDR2207 | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 180µH | |
| Tolerance | ±10% | |
| Current Rating | 1.3A | |
| Current - Saturation | 2.5A | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 300 mOhm Max | |
| Q @ Freq | 20 @ 2MHz | |
| Frequency - Self Resonant | 5.7MHz | |
| Operating Temperature | -40°C ~ 125°C | |
| Frequency - Test | 100kHz | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard | |
| Size / Dimension | 0.866" L x 0.591" W (22.00mm x 15.00mm) | |
| Height - Seated (Max) | 0.307" (7.80mm) | |
| Supplier Device Package | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SDR2207-181KL | |
| Related Links | SDR220, SDR2207-181KL Datasheet, Bourns Inc. Distributor | |
