Sullins Connector Solutions SDS101-PRW2-F09-SN00-1
- Mfg. Part Number
- SDS101-PRW2-F09-SN00-1
- Manufacturer
- Sullins Connector Solutions
- Product Category
- D-Sub Connectors
- Brief Description
- D-Sub Connector Receptacle, Female Sockets 9 Position Through Hole Solder
- Datasheet Download
- SDS101-PRW2-F09-SN00-1.pdf
Availability of SDS101-PRW2-F09-SN00-1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SDS101-PRW2-F09-SN00-1, we specialize in Sullins Connector Solutions all series electronic components. SDS101-PRW2-F09-SN00-1 can be shipped within 24 hours after order. If you have any demands for SDS101-PRW2-F09-SN00-1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SDS101-PRW2-F09-SN00-1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SDS101-PRW2-F09-SN00-1
| Internal Part Number | EIS-SDS101-PRW2-F09-SN00-1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | D-Sub Series 05/Jan/2015 | |
| Standard Package | 50 | |
| Category | Connectors, Interconnects | |
| Family | D-Sub Connectors | |
| Series | 101 | |
| Packaging | Tray | |
| Connector Style | D-Sub | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 9 | |
| Number of Rows | 2 | |
| Shell Size, Connector Layout | 1 (DE, E) | |
| Contact Type | Signal | |
| Mounting Type | Through Hole | |
| Flange Feature | Housing/Shell (Unthreaded) | |
| Termination | Solder | |
| Features | - | |
| Shell Material, Finish | Tin Plated | |
| Contact Finish | Gold | |
| Contact Finish Thickness | Flash | |
| Ingress Protection | - | |
| Operating Temperature | - | |
| Voltage Rating | 250V | |
| Current Rating | 3A | |
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SDS101-PRW2-F09-SN00-1 | |
| Related Links | SDS101-PRW2, SDS101-PRW2-F09-SN00-1 Datasheet, Sullins Connector Solutions Distributor | |
