Curtis Industries SESCX-17
- Mfg. Part Number
- SESCX-17
- Manufacturer
- Curtis Industries
- Product Category
- Terminal Blocks - Barrier Blocks
- Brief Description
- Connector Barrier Block Strip 17 Circuit 0.250" (6.35mm)
- Datasheet Download
- SESCX-17.pdf
Availability of SESCX-17
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SESCX-17, we specialize in Curtis Industries all series electronic components. SESCX-17 can be shipped within 24 hours after order. If you have any demands for SESCX-17, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SESCX-17 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SESCX-17
| Internal Part Number | EIS-SESCX-17 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10 | |
| Category | Connectors, Interconnects | |
| Family | Terminal Blocks - Barrier Blocks | |
| Series | SE | |
| Packaging | Bulk | |
| Terminal Block Type | Barrier Block | |
| Number of Circuits | 17 | |
| Number of Wire Entries | 17 | |
| Pitch | 0.250" (6.35mm) | |
| Number of Rows | 1 | |
| Current Rating | 5A | |
| Voltage Rating | - | |
| Wire Gauge | 16-22 AWG | |
| Top Termination | Screws with Captive Plate | |
| Bottom Termination | Closed | |
| Barrier Type | 2 Wall (Dual) | |
| Features | Flange | |
| Color | - | |
| Terminal Screw Material | Brass | |
| Terminal Screw Finish | Nickel | |
| Mounting Type | Chassis, Panel | |
| Operating Temperature | 110°C | |
| Material - Insulation | Polyphenylene Oxide (PPO) | |
| Material Flammability Rating | UL94 V-0 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SESCX-17 | |
| Related Links | SESC, SESCX-17 Datasheet, Curtis Industries Distributor | |
