FFF SFW10R-2STAE1LF
- Mfg. Part Number
- SFW10R-2STAE1LF
- Manufacturer
- FFF
- Product Category
- FFC, FPC (Flat Flexible) Connectors
- Brief Description
- CONN FPC TOP 10POS 1MM SMD R/A
- Datasheet Download
- SFW10R-2STAE1LF.pdf
Availability of SFW10R-2STAE1LF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.55825
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SFW10R-2STAE1LF, we specialize in FFF all series electronic components. SFW10R-2STAE1LF can be shipped within 24 hours after order. If you have any demands for SFW10R-2STAE1LF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SFW10R-2STAE1LF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SFW10R-2STAE1LF
| Internal Part Number | EIS-SFW10R-2STAE1LF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 4,000 | |
| Category | Connectors, Interconnects | |
| Family | FFC, FPC (Flat Flexible) Connectors | |
| Series | SFW-R | |
| Packaging | Tape & Reel (TR) | |
| Flat Flex Type | FPC | |
| Mounting Type | Surface Mount, Right Angle | |
| Connector/Contact Type | Contacts, Top | |
| Number of Positions | 10 | |
| Pitch | 0.039" (1.00mm) | |
| Termination | Solder | |
| FFC, FCB Thickness | 0.33mm | |
| Height Above Board | 0.106" (2.70mm) | |
| Locking Feature | Slide Lock | |
| Cable End Type | Tapered | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Gold | |
| Housing Material | Polyphenylene Sulfide (PPS), Glass Filled | |
| Actuator Material | Polyphenylene Sulfide (PPS), Glass Filled | |
| Features | Zero Insertion Force (ZIF) | |
| Voltage Rating | 100V | |
| Operating Temperature | -55°C ~ 105°C | |
| Material Flammability Rating | UL94 V-0 | |
| Current Rating | 1A | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SFW10R-2STAE1LF | |
| Related Links | SFW10R-, SFW10R-2STAE1LF Datasheet, FFF Distributor | |
SFW10R-2STAE1LF Details Description
