Epson SGR-8002JF-PCM
- Mfg. Part Number
- SGR-8002JF-PCM
- Manufacturer
- Epson
- Product Category
- Programmable Oscillators
- Brief Description
- OSCILLATOR CMOS PROG 3.3V OE SMD
- Datasheet Download
- SGR-8002JF-PCM.pdf
Availability of SGR-8002JF-PCM
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.79180
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SGR-8002JF-PCM, we specialize in Epson all series electronic components. SGR-8002JF-PCM can be shipped within 24 hours after order. If you have any demands for SGR-8002JF-PCM, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SGR-8002JF-PCM Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SGR-8002JF-PCM
| Internal Part Number | EIS-SGR-8002JF-PCM | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | SPXO and VCXO | |
| Standard Package | 1 | |
| Category | Crystals and Oscillators | |
| Family | Programmable Oscillators | |
| Series | SG-8002 | |
| Packaging | Tube | |
| Type | Programmed by Digi-Key (Enter your frequency in Web Order Notes) | |
| Available Frequency Range | 1MHz ~ 125MHz | |
| Function | Enable/Disable | |
| Output | CMOS | |
| Voltage - Supply | 3.3V | |
| Frequency Stability | ±100ppm | |
| Operating Temperature | -40°C ~ 85°C | |
| Spread Spectrum Bandwidth | - | |
| Current - Supply (Max) | 28mA | |
| Mounting Type | Surface Mount | |
| Package / Case | 4-SOJ, 5.08mm pitch | |
| Height | 0.059" (1.50mm) | |
| Size / Dimension | 0.280" L x 0.181" W (7.10mm x 4.60mm) | |
| Current - Supply (Disable) (Max) | 16mA | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SGR-8002JF-PCM | |
| Related Links | SGR-800, SGR-8002JF-PCM Datasheet, Epson Distributor | |
SGR-8002JF-PCM Details Description
