Silicon Labs SIM3C157-B-GQ
- Mfg. Part Number
- SIM3C157-B-GQ
- Manufacturer
- Silicon Labs
- Product Category
- Embedded - Microcontrollers
- Brief Description
- MCU 32BIT 128KB 80TQFP
- Datasheet Download
- SIM3C157-B-GQ.pdf
Availability of SIM3C157-B-GQ
Available Quantity
5022 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 7.76000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SIM3C157-B-GQ, we specialize in Silicon Labs all series electronic components. SIM3C157-B-GQ can be shipped within 24 hours after order. If you have any demands for SIM3C157-B-GQ, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SIM3C157-B-GQ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SIM3C157-B-GQ
| Internal Part Number | EIS-SIM3C157-B-GQ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Precision32 MCU Family Clocking Options Precision32 CMSIS, HAL User Guide Getting Started with Precision32 IDE Integrating SiM3yyyyy Devices into Keil uVision IDE Getting Started with Precision32 AppBuilder Precision32 Port I/O Crossbar Decoder Precision32 si32Library Overview | |
| Product Training Modules | Precision32 ARM Cortex-M3 MCU Introduction | |
| Design Resources | Development Tool Selector | |
| Featured Product | Precision32™ Devices | |
| Standard Package | 119 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | SiM3C1xx | |
| Packaging | Tray | |
| Core Processor | ARM® Cortex®-M3 | |
| Core Size | 32-Bit | |
| Speed | 80MHz | |
| Connectivity | EBI/EMI, I²C, IrDA, SmartCard, SPI, UART/USART | |
| Peripherals | Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT | |
| Number of I/O | 65 | |
| Program Memory Size | 128KB (128K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 32K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 1.8 V ~ 3.6 V | |
| Data Converters | A/D 32x12b, D/A 2x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 80-TQFP | |
| Supplier Device Package | 80-TQFP (12x12) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SIM3C157-B-GQ | |
| Related Links | SIM3C1, SIM3C157-B-GQ Datasheet, Silicon Labs Distributor | |
