FFF SLD12R-2
- Mfg. Part Number
- SLD12R-2
- Manufacturer
- FFF
- Product Category
- FFC, FPC (Flat Flexible) Connectors
- Brief Description
- CONN FFC BOTTOM 12POS 1.25MM R/A
- Datasheet Download
- SLD12R-2.pdf
Availability of SLD12R-2
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SLD12R-2, we specialize in FFF all series electronic components. SLD12R-2 can be shipped within 24 hours after order. If you have any demands for SLD12R-2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SLD12R-2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SLD12R-2
| Internal Part Number | EIS-SLD12R-2 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | SLD Series (leaded) 12/Nov/2007 | |
| Standard Package | 2,280 | |
| Category | Connectors, Interconnects | |
| Family | FFC, FPC (Flat Flexible) Connectors | |
| Series | SLD | |
| Packaging | Tray | |
| Flat Flex Type | FFC, FPC | |
| Mounting Type | Through Hole, Right Angle | |
| Connector/Contact Type | Contacts, Bottom | |
| Number of Positions | 12 | |
| Pitch | 0.049" (1.25mm) | |
| Termination | Solder | |
| FFC, FCB Thickness | 0.30mm | |
| Height Above Board | 0.275" (6.99mm) | |
| Locking Feature | Slide Lock | |
| Cable End Type | Straight | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Tin Alloy | |
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled | |
| Actuator Material | Polybutylene Terephthalate (PBT), Glass Filled | |
| Features | Zero Insertion Force (ZIF) | |
| Voltage Rating | - | |
| Operating Temperature | - | |
| Material Flammability Rating | UL94 V-0 | |
| Current Rating | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SLD12R-2 | |
| Related Links | SLD1, SLD12R-2 Datasheet, FFF Distributor | |
SLD12R-2 Details Description
