FFF SLW20R-1C7
- Mfg. Part Number
- SLW20R-1C7
- Manufacturer
- FFF
- Product Category
- FFC, FPC (Flat Flexible) Connectors
- Brief Description
- CONN FFC BOTTOM 20POS 1.00MM R/A
- Datasheet Download
- SLW20R-1C7.pdf
Availability of SLW20R-1C7
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SLW20R-1C7, we specialize in FFF all series electronic components. SLW20R-1C7 can be shipped within 24 hours after order. If you have any demands for SLW20R-1C7, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SLW20R-1C7 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SLW20R-1C7
| Internal Part Number | EIS-SLW20R-1C7 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | FFC/FPC NON-LF 09/May/2012 | |
| Standard Package | 1,000 | |
| Category | Connectors, Interconnects | |
| Family | FFC, FPC (Flat Flexible) Connectors | |
| Series | SLW-R | |
| Packaging | Tray | |
| Flat Flex Type | FFC, FPC | |
| Mounting Type | Through Hole, Right Angle | |
| Connector/Contact Type | Contacts, Bottom | |
| Number of Positions | 20 | |
| Pitch | 0.039" (1.00mm) | |
| Termination | Kinked Pin | |
| FFC, FCB Thickness | 0.30mm, 0.33mm | |
| Height Above Board | 0.157" (4.00mm) | |
| Locking Feature | Slide Lock | |
| Cable End Type | Straight, Tapered | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Tin Alloy | |
| Housing Material | Polyamide (PA), Nylon, Glass Filled | |
| Actuator Material | Polyamide (PA), Nylon, Glass Filled | |
| Features | Zero Insertion Force (ZIF) | |
| Voltage Rating | - | |
| Operating Temperature | - | |
| Material Flammability Rating | UL94 V-0 | |
| Current Rating | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SLW20R-1C7 | |
| Related Links | SLW20, SLW20R-1C7 Datasheet, FFF Distributor | |
SLW20R-1C7 Details Description
