FFF SLW4R-1C7LF
- Mfg. Part Number
- SLW4R-1C7LF
- Manufacturer
- FFF
- Product Category
- FFC, FPC (Flat Flexible) Connectors
- Brief Description
- CONN FFC BOTTOM 4POS 1.00MM R/A
- Datasheet Download
- SLW4R-1C7LF.pdf
Availability of SLW4R-1C7LF
Available Quantity
8583 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.16665
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SLW4R-1C7LF, we specialize in FFF all series electronic components. SLW4R-1C7LF can be shipped within 24 hours after order. If you have any demands for SLW4R-1C7LF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SLW4R-1C7LF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SLW4R-1C7LF
| Internal Part Number | EIS-SLW4R-1C7LF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Flat Flex Connector Overview | |
| Featured Product | FFC and FPC Connectors | |
| PCN Assembly/Origin | FFC/FPC series 20/Jul/2011 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 260 | |
| Category | Connectors, Interconnects | |
| Family | FFC, FPC (Flat Flexible) Connectors | |
| Series | SLW-R | |
| Packaging | Tray | |
| Flat Flex Type | FFC, FPC | |
| Mounting Type | Through Hole, Right Angle | |
| Connector/Contact Type | Contacts, Bottom | |
| Number of Positions | 4 | |
| Pitch | 0.039" (1.00mm) | |
| Termination | Kinked Pin | |
| FFC, FCB Thickness | 0.30mm, 0.33mm | |
| Height Above Board | 0.157" (4.00mm) | |
| Locking Feature | Slide Lock | |
| Cable End Type | Straight, Tapered | |
| Contact Material | Phosphor Bronze | |
| Contact Finish | Tin | |
| Housing Material | Polyamide (PA), Nylon, Glass Filled | |
| Actuator Material | Polyamide (PA), Nylon, Glass Filled | |
| Features | Zero Insertion Force (ZIF) | |
| Voltage Rating | 100V | |
| Operating Temperature | -55°C ~ 85°C | |
| Material Flammability Rating | UL94 V-0 | |
| Current Rating | 1A | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SLW4R-1C7LF | |
| Related Links | SLW4R, SLW4R-1C7LF Datasheet, FFF Distributor | |
SLW4R-1C7LF Details Description
