Stackpole Electronics Inc. SM6227FB5R60
- Mfg. Part Number
- SM6227FB5R60
- Manufacturer
- Stackpole Electronics Inc.
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 5.6 OHM 1% 3W 6227
- Datasheet Download
- SM6227FB5R60.pdf
Availability of SM6227FB5R60
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.46550
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SM6227FB5R60, we specialize in Stackpole Electronics Inc. all series electronic components. SM6227FB5R60 can be shipped within 24 hours after order. If you have any demands for SM6227FB5R60, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SM6227FB5R60 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SM6227FB5R60
| Internal Part Number | EIS-SM6227FB5R60 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Pulse Handling Resistor Solutions | |
| RoHS Information | RoHS Compliance | |
| PCN Part Number | Global Part Number 9/Aug/2010 | |
| Standard Package | 1,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | SM | |
| Packaging | Bulk | |
| Resistance (Ohms) | 5.6 | |
| Tolerance | ±1% | |
| Power (Watts) | 3W | |
| Composition | Wirewound | |
| Features | Moisture Resistant, Pulse Withstanding | |
| Temperature Coefficient | ±100ppm/°C | |
| Operating Temperature | -55°C ~ 275°C | |
| Package / Case | 6227 J-Lead | |
| Supplier Device Package | 6227 | |
| Size / Dimension | 0.646" L x 0.276" W (16.40mm x 7.00mm) | |
| Height | 0.268" (6.80mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SM6227FB5R60 | |
| Related Links | SM6227, SM6227FB5R60 Datasheet, Stackpole Electronics Inc. Distributor | |
SM6227FB5R60 Details Description
