Microsemi Commercial Components SMBJ6.0CAE3/TR13
- Mfg. Part Number
- SMBJ6.0CAE3/TR13
- Manufacturer
- Microsemi Commercial Components
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 6VWM 10.3VC SMBJ
- Datasheet Download
- SMBJ6.0CAE3/TR13.pdf
Availability of SMBJ6.0CAE3/TR13
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.21600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SMBJ6.0CAE3/TR13, we specialize in Microsemi Commercial Components all series electronic components. SMBJ6.0CAE3/TR13 can be shipped within 24 hours after order. If you have any demands for SMBJ6.0CAE3/TR13, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SMBJ6.0CAE3/TR13 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SMBJ6.0CAE3/TR13
| Internal Part Number | EIS-SMBJ6.0CAE3/TR13 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | - | |
| Bidirectional Channels | 1 | |
| Voltage - Reverse Standoff (Typ) | 6V | |
| Voltage - Breakdown (Min) | 6.67V | |
| Voltage - Clamping (Max) @ Ipp | 10.3V | |
| Current - Peak Pulse (10/1000µs) | 58.3A | |
| Power - Peak Pulse | 600W | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | - | |
| Operating Temperature | -65°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AA, SMB | |
| Supplier Device Package | SMBJ (DO-214AA) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SMBJ6.0CAE3/TR13 | |
| Related Links | SMBJ6.0C, SMBJ6.0CAE3/TR13 Datasheet, Microsemi Commercial Components Distributor | |
