Micro Commercial Components (MCC) SMCJ7.5A-TP
.jpg)
- Mfg. Part Number
- SMCJ7.5A-TP
- Manufacturer
- Micro Commercial Components (MCC)
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 7.5VWM 12.9VC SMC
- Datasheet Download
- SMCJ7.5A-TP.pdf
Availability of SMCJ7.5A-TP
Available Quantity
8020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.15360
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SMCJ7.5A-TP, we specialize in Micro Commercial Components (MCC) all series electronic components. SMCJ7.5A-TP can be shipped within 24 hours after order. If you have any demands for SMCJ7.5A-TP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SMCJ7.5A-TP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SMCJ7.5A-TP
| Internal Part Number | EIS-SMCJ7.5A-TP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Transient Voltage Suppressors Diode Handling and Mounting | |
| Featured Product | Surface Mount TVS | |
| PCN Design/Specification | TVS Breakdown Voltage 15/May/2013 | |
| Standard Package | 3,000 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | 1 | |
| Bidirectional Channels | - | |
| Voltage - Reverse Standoff (Typ) | 7.5V | |
| Voltage - Breakdown (Min) | 8.3V | |
| Voltage - Clamping (Max) @ Ipp | 12.9V | |
| Current - Peak Pulse (10/1000µs) | 116.3A | |
| Power - Peak Pulse | 1500W (1.5kW) | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | - | |
| Operating Temperature | -55°C ~ 175°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AB, SMC | |
| Supplier Device Package | DO-214AB, (SMC) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SMCJ7.5A-TP | |
| Related Links | SMCJ7, SMCJ7.5A-TP Datasheet, Micro Commercial Components (MCC) Distributor | |
SMCJ7.5A-TP Details Description
