Vishay Semiconductor/Diodes Division SMF28A-M3-08
- Mfg. Part Number
- SMF28A-M3-08
- Manufacturer
- Vishay Semiconductor/Diodes Division
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 28VWM 45.4VC DO-219AB
- Datasheet Download
- SMF28A-M3-08.pdf
Availability of SMF28A-M3-08
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.08113
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SMF28A-M3-08, we specialize in Vishay Semiconductor/Diodes Division all series electronic components. SMF28A-M3-08 can be shipped within 24 hours after order. If you have any demands for SMF28A-M3-08, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SMF28A-M3-08 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SMF28A-M3-08
| Internal Part Number | EIS-SMF28A-M3-08 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | 1 | |
| Bidirectional Channels | - | |
| Voltage - Reverse Standoff (Typ) | 28V | |
| Voltage - Breakdown (Min) | 31.1V | |
| Voltage - Clamping (Max) @ Ipp | 45.4V | |
| Current - Peak Pulse (10/1000µs) | 4.4A | |
| Power - Peak Pulse | 200W | |
| Power Line Protection | No | |
| Applications | General Purpose | |
| Capacitance @ Frequency | 227pF @ 1MHz | |
| Operating Temperature | -65°C ~ 175°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-219AB | |
| Supplier Device Package | SMF (DO-219AB) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SMF28A-M3-08 | |
| Related Links | SMF28A, SMF28A-M3-08 Datasheet, Vishay Semiconductor/Diodes Division Distributor | |
SMF28A-M3-08 Details Description
