Texas Instruments SN74ACT563PW
- Mfg. Part Number
- SN74ACT563PW
- Manufacturer
- Texas Instruments
- Product Category
- Logic - Latches
- Brief Description
- IC OCTAL D TRANSP LATCH 20-TSSOP
- Datasheet Download
- SN74ACT563PW.pdf
Availability of SN74ACT563PW
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.37800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SN74ACT563PW, we specialize in Texas Instruments all series electronic components. SN74ACT563PW can be shipped within 24 hours after order. If you have any demands for SN74ACT563PW, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SN74ACT563PW Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SN74ACT563PW
| Internal Part Number | EIS-SN74ACT563PW | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 70 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Latches | |
| Series | 74ACT | |
| Packaging | Tube | |
| Logic Type | D-Type Transparent Latch | |
| Circuit | 8:8 | |
| Output Type | Tri-State | |
| Voltage - Supply | 4.5 V ~ 5.5 V | |
| Independent Circuits | 1 | |
| Delay Time - Propagation | 6.5ns | |
| Current - Output High, Low | 24mA, 24mA | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 20-TSSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 20-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SN74ACT563PW | |
| Related Links | SN74AC, SN74ACT563PW Datasheet, Texas Instruments Distributor | |
