Texas Instruments SN74HC7002DR
- Mfg. Part Number
- SN74HC7002DR
- Manufacturer
- Texas Instruments
- Product Category
- Logic - Gates and Inverters
- Brief Description
- IC GATE NOR 4CH 2-INP 14-SOIC
- Datasheet Download
- SN74HC7002DR.pdf
Availability of SN74HC7002DR
Available Quantity
10020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.12500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SN74HC7002DR, we specialize in Texas Instruments all series electronic components. SN74HC7002DR can be shipped within 24 hours after order. If you have any demands for SN74HC7002DR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SN74HC7002DR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SN74HC7002DR
| Internal Part Number | EIS-SN74HC7002DR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Gates and Inverters | |
| Series | 74HC | |
| Packaging | Tape & Reel (TR) | |
| Logic Type | NOR Gate | |
| Number of Circuits | 4 | |
| Number of Inputs | 2 | |
| Features | Schmitt Trigger | |
| Voltage - Supply | 2 V ~ 6 V | |
| Current - Quiescent (Max) | 2µA | |
| Current - Output High, Low | 5.2mA, 5.2mA | |
| Logic Level - Low | 0.3 V ~ 1.2 V | |
| Logic Level - High | 1.5 V ~ 4.2 V | |
| Max Propagation Delay @ V, Max CL | 22ns @ 6V, 50pF | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Supplier Device Package | 14-SOIC | |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SN74HC7002DR | |
| Related Links | SN74HC, SN74HC7002DR Datasheet, Texas Instruments Distributor | |
