Texas Instruments SN74LVC821ADBRG4
- Mfg. Part Number
- SN74LVC821ADBRG4
- Manufacturer
- Texas Instruments
- Product Category
- Logic - Flip Flops
- Brief Description
- IC D-TYPE POS TRG SNGL 24SSOP
- Datasheet Download
- SN74LVC821ADBRG4.pdf
Availability of SN74LVC821ADBRG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.53900
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SN74LVC821ADBRG4, we specialize in Texas Instruments all series electronic components. SN74LVC821ADBRG4 can be shipped within 24 hours after order. If you have any demands for SN74LVC821ADBRG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SN74LVC821ADBRG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SN74LVC821ADBRG4
| Internal Part Number | EIS-SN74LVC821ADBRG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Flip Flops | |
| Series | 74LVC | |
| Packaging | Tape & Reel (TR) | |
| Function | Standard | |
| Type | D-Type | |
| Output Type | Tri-State, Non-Inverted | |
| Number of Elements | 1 | |
| Number of Bits per Element | 10 | |
| Frequency - Clock | 150MHz | |
| Max Propagation Delay @ V, Max CL | 7.3ns @ 3.3V, 50pF | |
| Trigger Type | Positive Edge | |
| Current - Output High, Low | 24mA, 24mA | |
| Voltage - Supply | 1.65 V ~ 3.6 V | |
| Current - Quiescent | 10µA | |
| Input Capacitance | 5pF | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 24-SSOP (0.209", 5.30mm Width) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SN74LVC821ADBRG4 | |
| Related Links | SN74LVC8, SN74LVC821ADBRG4 Datasheet, Texas Instruments Distributor | |
SN74LVC821ADBRG4 Details Description
