Fairchild Semiconductor SSM1N45BTF
- Mfg. Part Number
- SSM1N45BTF
- Manufacturer
- Fairchild Semiconductor
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 450V 500MA SOT-223
- Datasheet Download
- SSM1N45BTF.pdf
Availability of SSM1N45BTF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SSM1N45BTF, we specialize in Fairchild Semiconductor all series electronic components. SSM1N45BTF can be shipped within 24 hours after order. If you have any demands for SSM1N45BTF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SSM1N45BTF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SSM1N45BTF
| Internal Part Number | EIS-SSM1N45BTF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 4,000 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 450V | |
| Current - Continuous Drain (Id) @ 25°C | 500mA (Tc) | |
| Rds On (Max) @ Id, Vgs | 4.25 Ohm @ 250mA, 10V | |
| Vgs(th) (Max) @ Id | 3.7V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 8.5nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 240pF @ 25V | |
| Power - Max | 900mW | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-261-4, TO-261AA | |
| Supplier Device Package | SOT-223-3 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SSM1N45BTF | |
| Related Links | SSM1N, SSM1N45BTF Datasheet, Fairchild Semiconductor Distributor | |
SSM1N45BTF Details Description
