Samtec, Inc. SSW-147-01-S-S
- Mfg. Part Number
- SSW-147-01-S-S
- Manufacturer
- Samtec, Inc.
- Product Category
- Rectangular Connectors - Headers, Receptacles, Female Sockets
- Brief Description
- Connector Receptacle 47 Position 0.100" (2.54mm) Gold Through Hole
- Datasheet Download
- SSW-147-01-S-S.pdf
Availability of SSW-147-01-S-S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.49405
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SSW-147-01-S-S, we specialize in Samtec, Inc. all series electronic components. SSW-147-01-S-S can be shipped within 24 hours after order. If you have any demands for SSW-147-01-S-S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SSW-147-01-S-S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SSW-147-01-S-S
| Internal Part Number | EIS-SSW-147-01-S-S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Board-to-Board Connectors | |
| Featured Product | Board-To-Board Interconnect Systems | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Rectangular Connectors - Headers, Receptacles, Female Sockets | |
| Series | SSW | |
| Packaging | Bulk | |
| Connector Type | Receptacle | |
| Contact Type | Female Socket | |
| Number of Positions | 47 | |
| Number of Positions Loaded | All | |
| Pitch | 0.100" (2.54mm) | |
| Number of Rows | 1 | |
| Row Spacing | - | |
| Mounting Type | Through Hole | |
| Termination | Solder | |
| Fastening Type | - | |
| Features | - | |
| Contact Finish | Gold | |
| Contact Finish Thickness | 30µin (0.76µm) | |
| Color | Black | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SSW-147-01-S-S | |
| Related Links | SSW-147, SSW-147-01-S-S Datasheet, Samtec, Inc. Distributor | |
SSW-147-01-S-S Details Description
