Apem Inc. ST26L2DWB
- Mfg. Part Number
- ST26L2DWB
- Manufacturer
- Apem Inc.
- Product Category
- Toggle Switches
- Brief Description
- SWITCH TOGGLE SP3T 0.4VA 20V
- Datasheet Download
- ST26L2DWB.pdf
Availability of ST26L2DWB
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ST26L2DWB, we specialize in Apem Inc. all series electronic components. ST26L2DWB can be shipped within 24 hours after order. If you have any demands for ST26L2DWB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ST26L2DWB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ST26L2DWB
| Internal Part Number | EIS-ST26L2DWB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 25 | |
| Category | Switches | |
| Family | Toggle Switches | |
| Series | ST | |
| Packaging | Bulk | |
| Circuit | SP3T | |
| Switch Function | On-On-On | |
| Current Rating | 0.4VA (AC/DC) | |
| Voltage Rating - AC | 20V | |
| Voltage Rating - DC | 20V | |
| Actuator Type | Standard Round | |
| Actuator Length | 6.86mm | |
| Illumination | Non-Illuminated | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount | |
| Termination Style | Wire Wrap | |
| Panel Cutout Dimensions | Circular - 6.35mm Dia | |
| Bushing Thread | 1/4-40 | |
| Ingress Protection | - | |
| Features | Jumper needed to achieve triple throw | |
| Actuator Material | Brass, Nickel Plated | |
| Electrical Life | 40,000 Cycles | |
| Operating Temperature | -30°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ST26L2DWB | |
| Related Links | ST26, ST26L2DWB Datasheet, Apem Inc. Distributor | |
ST26L2DWB Details Description
