ST STL15N60M2-EP
- Mfg. Part Number
- STL15N60M2-EP
- Manufacturer
- ST
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 600V 7A PWRFLAT HV
- Datasheet Download
- STL15N60M2-EP.pdf
Availability of STL15N60M2-EP
Available Quantity
5420 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.05194
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of STL15N60M2-EP, we specialize in ST all series electronic components. STL15N60M2-EP can be shipped within 24 hours after order. If you have any demands for STL15N60M2-EP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- STL15N60M2-EP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
STL15N60M2-EP
| Internal Part Number | EIS-STL15N60M2-EP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | 600 V MDmesh M2 EP MOSFETs | |
| Standard Package | 1 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | MDmesh™ M2 | |
| Packaging | Cut Tape (CT) | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 600V | |
| Current - Continuous Drain (Id) @ 25°C | 7A (Tc) | |
| Rds On (Max) @ Id, Vgs | 418 mOhm @ 4.5A, 10V | |
| Vgs(th) (Max) @ Id | 4V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 17nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 590pF @ 100V | |
| Power - Max | 55W | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-PowerVDFN | |
| Supplier Device Package | PowerFlat™ (5x6) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | STL15N60M2-EP | |
| Related Links | STL15N, STL15N60M2-EP Datasheet, ST Distributor | |
STL15N60M2-EP Details Description
