ST STS17NH3LL
- Mfg. Part Number
- STS17NH3LL
- Manufacturer
- ST
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 30V 17A 8-SOIC
- Datasheet Download
- STS17NH3LL.pdf
Availability of STS17NH3LL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of STS17NH3LL, we specialize in ST all series electronic components. STS17NH3LL can be shipped within 24 hours after order. If you have any demands for STS17NH3LL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- STS17NH3LL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
STS17NH3LL
| Internal Part Number | EIS-STS17NH3LL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | STripFET™ | |
| Packaging | Tape & Reel (TR) | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 30V | |
| Current - Continuous Drain (Id) @ 25°C | 17A (Tc) | |
| Rds On (Max) @ Id, Vgs | 5.7 mOhm @ 8.5A, 10V | |
| Vgs(th) (Max) @ Id | 1V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 24nC @ 4.5V | |
| Input Capacitance (Ciss) @ Vds | 1810pF @ 25V | |
| Power - Max | 2.7W | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SO | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | STS17NH3LL | |
| Related Links | STS17, STS17NH3LL Datasheet, ST Distributor | |
STS17NH3LL Details Description
