ON Semiconductor SZP6SMB82AT3G
- Mfg. Part Number
- SZP6SMB82AT3G
- Manufacturer
- ON Semiconductor
- Product Category
- TVS - Diodes
- Brief Description
- TVS DIODE 70.1VWM 113VC SMB
- Datasheet Download
- SZP6SMB82AT3G.pdf
Availability of SZP6SMB82AT3G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.20863
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of SZP6SMB82AT3G, we specialize in ON Semiconductor all series electronic components. SZP6SMB82AT3G can be shipped within 24 hours after order. If you have any demands for SZP6SMB82AT3G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- SZP6SMB82AT3G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
SZP6SMB82AT3G
| Internal Part Number | EIS-SZP6SMB82AT3G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,500 | |
| Category | Circuit Protection | |
| Family | TVS - Diodes | |
| Series | Automotive, AEC-Q101 | |
| Packaging | Tape & Reel (TR) | |
| Type | Zener | |
| Unidirectional Channels | 1 | |
| Bidirectional Channels | - | |
| Voltage - Reverse Standoff (Typ) | 70.1V | |
| Voltage - Breakdown (Min) | 77.9V | |
| Voltage - Clamping (Max) @ Ipp | 113V | |
| Current - Peak Pulse (10/1000µs) | 5.3A | |
| Power - Peak Pulse | 600W | |
| Power Line Protection | No | |
| Applications | Automotive | |
| Capacitance @ Frequency | 260pF @ 1MHz | |
| Operating Temperature | -65°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | DO-214AA, SMB | |
| Supplier Device Package | SMB | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | SZP6SMB82AT3G | |
| Related Links | SZP6SM, SZP6SMB82AT3G Datasheet, ON Semiconductor Distributor | |
