Microchip Technology TC110301ECTTR
- Mfg. Part Number
- TC110301ECTTR
- Manufacturer
- Microchip Technology
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Controllers
- Brief Description
- IC REG CTRLR BST PWM SOT23A-5
- Datasheet Download
- TC110301ECTTR.pdf
Availability of TC110301ECTTR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.72000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TC110301ECTTR, we specialize in Microchip Technology all series electronic components. TC110301ECTTR can be shipped within 24 hours after order. If you have any demands for TC110301ECTTR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TC110301ECTTR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TC110301ECTTR
| Internal Part Number | EIS-TC110301ECTTR | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Packaging | Label and Packing Changes 23/Sep/2015 | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Controllers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Number of Outputs | 1 | |
| Frequency - Max | 115kHz | |
| Duty Cycle | 92% | |
| Voltage - Supply | 2 V ~ 10 V | |
| Buck | No | |
| Boost | Yes | |
| Flyback | No | |
| Inverting | No | |
| Doubler | No | |
| Divider | No | |
| Cuk | No | |
| Isolated | No | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | SC-74A, SOT-753 | |
| Supplier Device Package | SOT-23-5 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TC110301ECTTR | |
| Related Links | TC1103, TC110301ECTTR Datasheet, Microchip Technology Distributor | |
