Kyocera Display TCG121XGLPBPNN-AN40
- Mfg. Part Number
- TCG121XGLPBPNN-AN40
- Manufacturer
- Kyocera Display
- Product Category
- Display Modules - LCD, OLED, Graphic
- Brief Description
- LCD MOD TFT 12.1" XGA TRANSMISS
- Datasheet Download
- TCG121XGLPBPNN-AN40.pdf
Availability of TCG121XGLPBPNN-AN40
Available Quantity
4000 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 512.89000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TCG121XGLPBPNN-AN40, we specialize in Kyocera Display all series electronic components. TCG121XGLPBPNN-AN40 can be shipped within 24 hours after order. If you have any demands for TCG121XGLPBPNN-AN40, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TCG121XGLPBPNN-AN40 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TCG121XGLPBPNN-AN40
| Internal Part Number | EIS-TCG121XGLPBPNN-AN40 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | 12.1” XGA TFT Display | |
| PCN Design/Specification | Tape change 27/nov/2015 | |
| Standard Package | 10 | |
| Category | Optoelectronics | |
| Family | Display Modules - LCD, OLED, Graphic | |
| Series | - | |
| Display Type | TFT - Color | |
| Display Mode | Transmissive | |
| Touchscreen | - | |
| Diagonal Screen Size | 12.1" (307.34mm) | |
| Viewing Area | 261.12mm W x 163.20mm H | |
| Backlight | LED - White | |
| Dot Pixels | 1280 x 800 (WXGA1) | |
| Interface | LVDS | |
| Graphics Color | Red, Green, Blue (RGB) | |
| Background Color | - | |
| Dot Size | - | |
| Dot Pitch | 0.07mm W x 0.20mm H | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TCG121XGLPBPNN-AN40 | |
| Related Links | TCG121XGL, TCG121XGLPBPNN-AN40 Datasheet, Kyocera Display Distributor | |
TCG121XGLPBPNN-AN40 Details Description
