C&K Components TF2CHK6SP0010C
- Mfg. Part Number
- TF2CHK6SP0010C
- Manufacturer
- C&K Components
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SWITCH SNAP ACT 125V
- Datasheet Download
- TF2CHK6SP0010C.pdf
Availability of TF2CHK6SP0010C
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.89610
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TF2CHK6SP0010C, we specialize in C&K Components all series electronic components. TF2CHK6SP0010C can be shipped within 24 hours after order. If you have any demands for TF2CHK6SP0010C, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TF2CHK6SP0010C Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TF2CHK6SP0010C
| Internal Part Number | EIS-TF2CHK6SP0010C | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | TF2 Series Miniature Snap-Acting Switches | |
| Standard Package | 300 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | TF2 | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 10A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Round (Pin Plunger) | |
| Mounting Type | Chassis Mount | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Features | - | |
| Operating Force, Torque | 75gf | |
| Release Force | 14gf | |
| Pretravel | 0.068" (1.72mm) | |
| Differential Travel | 0.016" (0.4mm) | |
| Overtravel | 0.031" (0.79mm) | |
| Operating Position | 0.579" (14.7mm) | |
| Mechanical Life | - | |
| Electrical Life | 10,000 Cycles | |
| Operating Temperature | -40°C ~ 85°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TF2CHK6SP0010C | |
| Related Links | TF2CHK6, TF2CHK6SP0010C Datasheet, C&K Components Distributor | |
TF2CHK6SP0010C Details Description
