TDK Corporation TF6332TU-501Y25R0-01
- Mfg. Part Number
- TF6332TU-501Y25R0-01
- Manufacturer
- TDK Corporation
- Product Category
- Common Mode Chokes
- Brief Description
- FILTER LINE 0.5MH 25A HORIZONTAL
- Datasheet Download
- TF6332TU-501Y25R0-01.pdf
Availability of TF6332TU-501Y25R0-01
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TF6332TU-501Y25R0-01, we specialize in TDK Corporation all series electronic components. TF6332TU-501Y25R0-01 can be shipped within 24 hours after order. If you have any demands for TF6332TU-501Y25R0-01, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TF6332TU-501Y25R0-01 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TF6332TU-501Y25R0-01
| Internal Part Number | EIS-TF6332TU-501Y25R0-01 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10 | |
| Category | Filters | |
| Family | Common Mode Chokes | |
| Series | TF | |
| Packaging | Bulk | |
| Filter Type | Power Line | |
| Number of Lines | 3 | |
| Inductance | 500µH | |
| Current | 25A | |
| DC Resistance (DCR) | 6 Ohm Max | |
| Impedance | - | |
| Operating Temperature | -20°C ~ 120°C | |
| Mounting Type | Through Hole | |
| Size / Dimension | 2.480" Dia (63.00mm) | |
| Height (Max) | 1.260" (32.00mm) | |
| Package / Case | Horizontal, 4 PC Pin | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TF6332TU-501Y25R0-01 | |
| Related Links | TF6332TU-5, TF6332TU-501Y25R0-01 Datasheet, TDK Corporation Distributor | |
TF6332TU-501Y25R0-01 Details Description
