Bourns Inc. TIP2955-S
- Mfg. Part Number
- TIP2955-S
- Manufacturer
- Bourns Inc.
- Product Category
- Transistors (BJT) - Single
- Brief Description
- TRANS PNP 60V 15A
- Datasheet Download
- TIP2955-S.pdf
Availability of TIP2955-S
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TIP2955-S, we specialize in Bourns Inc. all series electronic components. TIP2955-S can be shipped within 24 hours after order. If you have any demands for TIP2955-S, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TIP2955-S Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TIP2955-S
| Internal Part Number | EIS-TIP2955-S | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | SOT-93 Bipolar Transistors 03/Apr/2012 | |
| Standard Package | 1,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors (BJT) - Single | |
| Series | - | |
| Packaging | Tube | |
| Transistor Type | PNP | |
| Current - Collector (Ic) (Max) | 15A | |
| Voltage - Collector Emitter Breakdown (Max) | 60V | |
| Vce Saturation (Max) @ Ib, Ic | 3V @ 3.3A, 10A | |
| Current - Collector Cutoff (Max) | 700µA | |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 20 @ 4A, 4V | |
| Power - Max | 3.5W | |
| Frequency - Transition | - | |
| Mounting Type | Through Hole | |
| Package / Case | TO-218-3 | |
| Supplier Device Package | SOT-93 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TIP2955-S | |
| Related Links | TIP2, TIP2955-S Datasheet, Bourns Inc. Distributor | |
TIP2955-S Details Description
