Texas Instruments TLC0834CDRG4
- Mfg. Part Number
- TLC0834CDRG4
- Manufacturer
- Texas Instruments
- Product Category
- Data Acquisition - Analog to Digital Converters (ADC)
- Brief Description
- IC ADC 8BIT 4CH SRL I/O 14-SOIC
- Datasheet Download
- TLC0834CDRG4.pdf
Availability of TLC0834CDRG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.70905
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TLC0834CDRG4, we specialize in Texas Instruments all series electronic components. TLC0834CDRG4 can be shipped within 24 hours after order. If you have any demands for TLC0834CDRG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TLC0834CDRG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TLC0834CDRG4
| Internal Part Number | EIS-TLC0834CDRG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Data Converter Basics | |
| Manufacturer Product Page | TLC0834CDRG4 Specifications | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Analog to Digital Converters (ADC) | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Number of Bits | 8 | |
| Sampling Rate (Per Second) | 20k | |
| Number of Inputs | 2, 3, 4 | |
| Input Type | Differential, Pseudo-Differential, Single Ended | |
| Data Interface | SPI | |
| Configuration | MUX-ADC | |
| Ratio - S/H:ADC | - | |
| Number of A/D Converters | 1 | |
| Architecture | SAR | |
| Reference Type | External | |
| Voltage - Supply, Analog | 5V | |
| Voltage - Supply, Digital | 5V | |
| Features | - | |
| Operating Temperature | 0°C ~ 70°C | |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 14-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TLC0834CDRG4 | |
| Related Links | TLC083, TLC0834CDRG4 Datasheet, Texas Instruments Distributor | |
