Texas Instruments TLC2274AMDG4
- Mfg. Part Number
- TLC2274AMDG4
- Manufacturer
- Texas Instruments
- Product Category
- Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
- Brief Description
- IC OPAMP GP 2.25MHZ RRO 14SOIC
- Datasheet Download
- TLC2274AMDG4.pdf
Availability of TLC2274AMDG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.76000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TLC2274AMDG4, we specialize in Texas Instruments all series electronic components. TLC2274AMDG4 can be shipped within 24 hours after order. If you have any demands for TLC2274AMDG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TLC2274AMDG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TLC2274AMDG4
| Internal Part Number | EIS-TLC2274AMDG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Create your power design now with TI’s WEBENCH® Designer | |
| PCN Assembly/Origin | Wafer Diameter Update 23/Sep/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps | |
| Series | LinCMOS™ | |
| Packaging | Tube | |
| Amplifier Type | General Purpose | |
| Number of Circuits | 4 | |
| Output Type | Rail-to-Rail | |
| Slew Rate | 3.6 V/µs | |
| Gain Bandwidth Product | 2.25MHz | |
| -3db Bandwidth | - | |
| Current - Input Bias | 1pA | |
| Voltage - Input Offset | 300µV | |
| Current - Supply | 4.8mA | |
| Current - Output / Channel | 50mA | |
| Voltage - Supply, Single/Dual (±) | 4.4 V ~ 16 V, ±2.2 V ~ 8 V | |
| Operating Temperature | -55°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 14-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TLC2274AMDG4 | |
| Related Links | TLC227, TLC2274AMDG4 Datasheet, Texas Instruments Distributor | |
TLC2274AMDG4 Details Description
