Texas Instruments TLC2934IPWG4
- Mfg. Part Number
- TLC2934IPWG4
- Manufacturer
- Texas Instruments
- Product Category
- Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
- Brief Description
- IC PHASE LOCK LOOP HP 14-TSSOP
- Datasheet Download
- TLC2934IPWG4.pdf
Availability of TLC2934IPWG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.77483
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TLC2934IPWG4, we specialize in Texas Instruments all series electronic components. TLC2934IPWG4 can be shipped within 24 hours after order. If you have any demands for TLC2934IPWG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TLC2934IPWG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TLC2934IPWG4
| Internal Part Number | EIS-TLC2934IPWG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 90 | |
| Category | Integrated Circuits (ICs) | |
| Family | Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers | |
| Series | - | |
| Packaging | Tube | |
| Type | Phase Lock Loop (PLL) | |
| PLL | Yes | |
| Input | Clock | |
| Output | Clock | |
| Number of Circuits | 1 | |
| Ratio - Input:Output | 2:1 | |
| Differential - Input:Output | No/No | |
| Frequency - Max | 130MHz | |
| Divider/Multiplier | Yes/No | |
| Voltage - Supply | 3.15 V ~ 3.45 V | |
| Operating Temperature | -20°C ~ 75°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 14-TSSOP (0.173", 4.40mm Width) | |
| Supplier Device Package | 14-TSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TLC2934IPWG4 | |
| Related Links | TLC293, TLC2934IPWG4 Datasheet, Texas Instruments Distributor | |
TLC2934IPWG4 Details Description
