Analog TMP36FS
- Mfg. Part Number
- TMP36FS
- Manufacturer
- Analog
- Product Category
- Temperature Sensors, Transducers
- Brief Description
- SENSOR TEMP RATIOMETRIC 8SOIC
- Datasheet Download
- TMP36FS.pdf
Availability of TMP36FS
Available Quantity
5069 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.88920
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TMP36FS, we specialize in Analog all series electronic components. TMP36FS can be shipped within 24 hours after order. If you have any demands for TMP36FS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TMP36FS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TMP36FS
| Internal Part Number | EIS-TMP36FS | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Automotive Sensor and Sensor Interface Solution | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 98 | |
| Category | Sensors, Transducers | |
| Family | Temperature Sensors, Transducers | |
| Series | - | |
| Packaging | Tube | |
| Sensor Type | Analog, Local | |
| Sensing Temperature - Local | -40°C ~ 125°C | |
| Sensing Temperature - Remote | - | |
| Output Type | Ratiometric, Voltage | |
| Voltage - Supply | 2.7 V ~ 5.5 V | |
| Resolution | 10mV/°C | |
| Features | Shutdown Mode | |
| Accuracy - Highest (Lowest) | ±2°C (±3°C) | |
| Test Condition | 25°C (-40°C ~ 125°C) | |
| Operating Temperature | -40°C ~ 150°C | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TMP36FS | |
| Related Links | TMP, TMP36FS Datasheet, Analog Distributor | |
TMP36FS Details Description
