Texas Instruments TMS320R2812GHHA
- Mfg. Part Number
- TMS320R2812GHHA
- Manufacturer
- Texas Instruments
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 32BIT ROMLESS 179BGA
- Datasheet Download
- TMS320R2812GHHA.pdf
Availability of TMS320R2812GHHA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 11.98125
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TMS320R2812GHHA, we specialize in Texas Instruments all series electronic components. TMS320R2812GHHA can be shipped within 24 hours after order. If you have any demands for TMS320R2812GHHA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TMS320R2812GHHA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TMS320R2812GHHA
| Internal Part Number | EIS-TMS320R2812GHHA | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Microcontrollers: ControlSUITE - Comprehensive software for the entire design process Motor Signal Chain Overview TPS75005 Single IC Power for C2000 MCU Intro to Timers and Clocks Microcontrollers: SYS/BIOS: Introduction to Real-Time Operating Systems and SYS/BIOS | |
| Design Resources | Development Tool Selector | |
| PCN Design/Specification | QFP/BGA Packages Wire Diameter 24/May/2013 | |
| PCN Packaging | 12x12 BGA Tray Change 21/Aug/2013 | |
| Manufacturer Product Page | TMS320R2812GHHA Specifications | |
| Standard Package | 160 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | C2000™ C28x Fixed-Point | |
| Packaging | Tray | |
| Core Processor | C28x | |
| Core Size | 32-Bit | |
| Speed | 150MHz | |
| Connectivity | CAN, EBI/EMI, I²C, McBSP, SCI, SPI, UART/USART | |
| Peripherals | DMA, POR, PWM, WDT | |
| Number of I/O | 56 | |
| Program Memory Size | - | |
| Program Memory Type | ROMless | |
| EEPROM Size | - | |
| RAM Size | 20K x 16 | |
| Voltage - Supply (Vcc/Vdd) | 1.81 V ~ 2 V | |
| Data Converters | A/D 16x12b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 179-LFBGA | |
| Supplier Device Package | 179-BGA MicroStar (12x12) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TMS320R2812GHHA | |
| Related Links | TMS320R, TMS320R2812GHHA Datasheet, Texas Instruments Distributor | |
TMS320R2812GHHA Details Description
