Vishay/Dale TNPW1210196KBETA
.jpg)
- Mfg. Part Number
- TNPW1210196KBETA
- Manufacturer
- Vishay/Dale
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 196K OHM 0.1% 1/3W 1210
- Datasheet Download
- TNPW1210196KBETA.pdf
Availability of TNPW1210196KBETA
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.47175
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TNPW1210196KBETA, we specialize in Vishay/Dale all series electronic components. TNPW1210196KBETA can be shipped within 24 hours after order. If you have any demands for TNPW1210196KBETA, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TNPW1210196KBETA Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TNPW1210196KBETA
| Internal Part Number | EIS-TNPW1210196KBETA | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 5,000 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | TNPW | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 196k | |
| Tolerance | ±0.1% | |
| Power (Watts) | 0.333W, 1/3W | |
| Composition | Thin Film | |
| Features | - | |
| Temperature Coefficient | ±25ppm/°C | |
| Operating Temperature | -55°C ~ 125°C | |
| Package / Case | 1210 (3225 Metric) | |
| Supplier Device Package | 1210 | |
| Size / Dimension | 0.126" L x 0.096" W (3.20mm x 2.45mm) | |
| Height | 0.030" (0.75mm) | |
| Number of Terminations | 2 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TNPW1210196KBETA | |
| Related Links | TNPW1210, TNPW1210196KBETA Datasheet, Vishay/Dale Distributor | |
