Toshiba Semiconductor & Storage TPC8045-H(TE12L,QM
- Mfg. Part Number
- TPC8045-H(TE12L,QM
- Manufacturer
- Toshiba Semiconductor & Storage
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 40V 18A 8-SOP
- Datasheet Download
- TPC8045-H(TE12L,QM.pdf
Availability of TPC8045-H(TE12L,QM
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.92880
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TPC8045-H(TE12L,QM, we specialize in Toshiba Semiconductor & Storage all series electronic components. TPC8045-H(TE12L,QM can be shipped within 24 hours after order. If you have any demands for TPC8045-H(TE12L,QM, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TPC8045-H(TE12L,QM Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TPC8045-H(TE12L,QM
| Internal Part Number | EIS-TPC8045-H(TE12L,QM | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 3,000 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 40V | |
| Current - Continuous Drain (Id) @ 25°C | 18A (Ta) | |
| Rds On (Max) @ Id, Vgs | 3.9 mOhm @ 9A, 10V | |
| Vgs(th) (Max) @ Id | 2.3V @ 1mA | |
| Gate Charge (Qg) @ Vgs | 90nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 7540pF @ 10V | |
| Power - Max | - | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.173", 4.40mm Width) | |
| Supplier Device Package | 8-SOP (5.5x6.0) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TPC8045-H(TE12L,QM | |
| Related Links | TPC8045-H, TPC8045-H(TE12L,QM Datasheet, Toshiba Semiconductor & Storage Distributor | |
