Texas Instruments TPIC46L02DBG4
- Mfg. Part Number
- TPIC46L02DBG4
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Gate Drivers
- Brief Description
- IC DRIVER PRE FET 6 CHAN 28SSOP
- Datasheet Download
- TPIC46L02DBG4.pdf
Availability of TPIC46L02DBG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.12500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TPIC46L02DBG4, we specialize in Texas Instruments all series electronic components. TPIC46L02DBG4 can be shipped within 24 hours after order. If you have any demands for TPIC46L02DBG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TPIC46L02DBG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TPIC46L02DBG4
| Internal Part Number | EIS-TPIC46L02DBG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Packaging | End Plug Material Update 24/Apr/2014 Carrier Tape Revision A 30/Mar/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Series | - | |
| Packaging | Tube | |
| Configuration | Low-Side | |
| Input Type | Non-Inverting | |
| Delay Time | 4µs | |
| Current - Peak | 1.2mA | |
| Number of Configurations | 6 | |
| Number of Outputs | 6 | |
| High Side Voltage - Max (Bootstrap) | - | |
| Voltage - Supply | 4.5 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 28-SSOP (0.209", 5.30mm Width) | |
| Supplier Device Package | 28-SSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TPIC46L02DBG4 | |
| Related Links | TPIC46, TPIC46L02DBG4 Datasheet, Texas Instruments Distributor | |
