Texas Instruments TPS2384APAP
- Mfg. Part Number
- TPS2384APAP
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Power Over Ethernet (PoE) Controllers
- Brief Description
- IC QUAD-PORT POE MANAGER 64HTQFP
- Datasheet Download
- TPS2384APAP.pdf
Availability of TPS2384APAP
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TPS2384APAP, we specialize in Texas Instruments all series electronic components. TPS2384APAP can be shipped within 24 hours after order. If you have any demands for TPS2384APAP, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TPS2384APAP Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TPS2384APAP
| Internal Part Number | EIS-TPS2384APAP | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 160 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Over Ethernet (PoE) Controllers | |
| Series | - | |
| Packaging | Tray | |
| Type | Controller (PSE) | |
| Number of Channels | 4 | |
| Power - Max | 15.4W | |
| Internal Switch(s) | Yes | |
| Auxiliary Sense | No | |
| Standards | 802.3af (PoE) | |
| Voltage - Supply | 44 V ~ 57 V | |
| Current - Supply | 10mA | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 64-TQFP Exposed Pad | |
| Supplier Device Package | 64-HTQFP (10x10) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TPS2384APAP | |
| Related Links | TPS23, TPS2384APAP Datasheet, Texas Instruments Distributor | |
TPS2384APAP Details Description
