Texas Instruments TPS2553QDBVRQ1
- Mfg. Part Number
- TPS2553QDBVRQ1
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Power Distribution Switches, Load Drivers
- Brief Description
- IC PWR DIST SWITCH ADJ SOT23-6
- Datasheet Download
- TPS2553QDBVRQ1.pdf
Availability of TPS2553QDBVRQ1
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.93250
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TPS2553QDBVRQ1, we specialize in Texas Instruments all series electronic components. TPS2553QDBVRQ1 can be shipped within 24 hours after order. If you have any demands for TPS2553QDBVRQ1, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TPS2553QDBVRQ1 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TPS2553QDBVRQ1
| Internal Part Number | EIS-TPS2553QDBVRQ1 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Manufacturer Product Page | TPS2553QDBVRQ1 Specifications | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Power Distribution Switches, Load Drivers | |
| Series | Automotive, AEC-Q100 | |
| Packaging | Tape & Reel (TR) | |
| Switch Type | General Purpose | |
| Number of Outputs | 1 | |
| Ratio - Input:Output | 1:1 | |
| Output Configuration | High Side | |
| Output Type | N-Channel | |
| Interface | On/Off | |
| Voltage - Load | 2.5 V ~ 6.5 V | |
| Voltage - Supply (Vcc/Vdd) | Not Required | |
| Current - Output (Max) | 1.5A | |
| Rds On (Typ) | 85 mOhm | |
| Input Type | Non-Inverting | |
| Features | Slew Rate Controlled, Status Flag | |
| Fault Protection | Current Limiting (Adjustable), Over Temperature, UVLO | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Package / Case | SOT-23-6 | |
| Supplier Device Package | SOT-23-6 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TPS2553QDBVRQ1 | |
| Related Links | TPS2553, TPS2553QDBVRQ1 Datasheet, Texas Instruments Distributor | |
TPS2553QDBVRQ1 Details Description
