Texas Instruments TPS40222DRPRG4
- Mfg. Part Number
- TPS40222DRPRG4
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG BUCK ADJ 1.6A 6SON
- Datasheet Download
- TPS40222DRPRG4.pdf
Availability of TPS40222DRPRG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.90625
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TPS40222DRPRG4, we specialize in Texas Instruments all series electronic components. TPS40222DRPRG4 can be shipped within 24 hours after order. If you have any demands for TPS40222DRPRG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TPS40222DRPRG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TPS40222DRPRG4
| Internal Part Number | EIS-TPS40222DRPRG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 2 (1 Year) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 3,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Function | Step-Down | |
| Output Configuration | Positive | |
| Topology | Buck | |
| Output Type | Adjustable | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 8V | |
| Voltage - Output (Min/Fixed) | 0.8V | |
| Voltage - Output (Max) | 7.2V | |
| Current - Output | 1.6A | |
| Frequency - Switching | 1.25MHz | |
| Synchronous Rectifier | No | |
| Operating Temperature | -40°C ~ 125°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 6-VDFN Exposed Pad | |
| Supplier Device Package | 6-VSON Exposed Pad (3x3) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TPS40222DRPRG4 | |
| Related Links | TPS4022, TPS40222DRPRG4 Datasheet, Texas Instruments Distributor | |
TPS40222DRPRG4 Details Description
