Thomas Research Products TRC-075S375ST
- Mfg. Part Number
- TRC-075S375ST
- Manufacturer
- Thomas Research Products
- Product Category
- LED Supplies
- Brief Description
- LED SUPPLY CC AC/DC 10-20V 3.75A
- Datasheet Download
- TRC-075S375ST.pdf
Availability of TRC-075S375ST
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 106.19000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TRC-075S375ST, we specialize in Thomas Research Products all series electronic components. TRC-075S375ST can be shipped within 24 hours after order. If you have any demands for TRC-075S375ST, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TRC-075S375ST Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TRC-075S375ST
| Internal Part Number | EIS-TRC-075S375ST | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| Standard Package | 1 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | LED Supplies | |
| Series | TRC-075 | |
| Type | Constant Current | |
| Topology | AC DC Converter | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 90VAC | |
| Voltage - Input (Max) | 305VAC | |
| Voltage - Output | 10 ~ 20 V | |
| Current - Output (Max) | 3.75A | |
| Power (Watts) | 75W | |
| Voltage - Isolation | - | |
| Dimming | - | |
| Features | OCP, OTP, OVP, SCP | |
| Ratings | IP67 | |
| Operating Temperature | -40°C ~ 70°C | |
| Efficiency | 87% | |
| Termination Style | Wire Leads | |
| Size / Dimension | 5.91" L x 2.66" W x 1.44" H (150.0mm x 67.5mm x 36.5mm) | |
| Mounting Type | Chassis Mount | |
| Approvals | CE, cULus | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TRC-075S375ST | |
| Related Links | TRC-07, TRC-075S375ST Datasheet, Thomas Research Products Distributor | |
