Vishay Semiconductor/Diodes Division TZQ5261B-GS18
- Mfg. Part Number
- TZQ5261B-GS18
- Manufacturer
- Vishay Semiconductor/Diodes Division
- Product Category
- Diodes - Zener - Single
- Brief Description
- DIODE ZENER 47V 500MW SOD80
- Datasheet Download
- TZQ5261B-GS18.pdf
Availability of TZQ5261B-GS18
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.02800
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of TZQ5261B-GS18, we specialize in Vishay Semiconductor/Diodes Division all series electronic components. TZQ5261B-GS18 can be shipped within 24 hours after order. If you have any demands for TZQ5261B-GS18, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- TZQ5261B-GS18 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
TZQ5261B-GS18
| Internal Part Number | EIS-TZQ5261B-GS18 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10,000 | |
| Category | Discrete Semiconductor Products | |
| Family | Diodes - Zener - Single | |
| Series | Automotive, AEC-Q101 | |
| Packaging | Tape & Reel (TR) | |
| Voltage - Zener (Nom) (Vz) | 47V | |
| Tolerance | ±5% | |
| Power - Max | 500mW | |
| Impedance (Max) (Zzt) | 105 Ohm | |
| Current - Reverse Leakage @ Vr | 100nA @ 36V | |
| Voltage - Forward (Vf) (Max) @ If | 1.5V @ 200mA | |
| Operating Temperature | -65°C ~ 175°C | |
| Mounting Type | Surface Mount | |
| Package / Case | SOD-80 Variant | |
| Supplier Device Package | SOD-80 QuadroMELF | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | TZQ5261B-GS18 | |
| Related Links | TZQ526, TZQ5261B-GS18 Datasheet, Vishay Semiconductor/Diodes Division Distributor | |
TZQ5261B-GS18 Details Description
